RINNAI
Rinnai Infinity 20
Rinnai Infinity 20
Couldn't load pickup availability
Never run out of hot water.
Unparalleled in performance, the Rinnai 20 Continuous Flow lets you enjoy the luxury of hot water that never runs out.
Ideal for one bathroom homes (up to two in warmer climates), the unit only heats water as needed, meaning you get a continuous supply of hot water without bill shock. With an impressive 6 star energy rating, the Rinnai Infinity 20 is the most energy efficient 20L continuous flow gas hot water system on the market.
Engineered to withstand tough Australian conditions, the slimline unit not only saves on space but comes equipped with an built-in temperature control display, enhanced safety monitoring and puretemp™ stability control.
Customise and complete your Infinity 20 hot water system with our comprehensive range of hot water controllers to enhance your experience
Specifications
|
Dimensions (mm) : Height |
571 |
|
Dimensions (mm) : Width |
356 |
|
Dimensions (mm) : Depth |
202 |
|
Colours |
White |
|
Factory Default Temperature (Celsius) |
50 or 60 |
|
Water Pressure (kPa) : Minimum |
160 |
|
Water Pressure (kPa) : Maximum |
1000 |
|
Gas Rate Max (Mj/h) : NG |
156 |
|
Flow Rate 25 Degrees C/Max : l/min |
20 |
|
Star Rating |
6.0* Equivalent |
|
Connection Sizes Gas/Hot/Cold (mm) |
20/20/20 |
|
Status Monitor |
Yes |
|
Dimensions (mm) : Height Inc Brackets |
571 |
|
Dimensions (mm) : Hot Water Outlet (From Wall) |
87 |
|
Dimensions (mm) : Hot Water Outlet (Left from Centre) |
105 |
|
Dimensions (mm) : Cold Water Inlet (From Wall) |
68 |
|
Dimensions (mm) : Cold Water Inlet (Right from Centre) |
10 |
|
Dimensions (mm) : Gas Connection (From Wall) |
77 |
|
Dimensions (mm) : Gas Connection (Right from Centre) |
83 |
|
Dimensions (mm) : Gas Connection Length (From Base) |
40 |
|
Dimensions (mm) : Cold Connection Length (From Base) |
50 |
|
Weight (kg) |
14.5 |
Infinity 20 - Continuous Flow Hot Water System - Rinnai Australia
* Independently calculated using Australian Standard AS5263.1.2. S5263.1.2 limits the rating shown on the energy label to 6.0 Stars. Where the calculated rating of Rinnai appliances exceeds 6.0 Stars it is designated as an “equivalent” rating.
Visit www.rinnai.com.au for full terms and conditions.
